No noise, no fumes, no limits.

Rizon e18M - Electric Truck

Battery packs: 2
Installed/Usable energy: 82/74 kWh
Possible range: 70-105 miles* (112-169 km*)

GVWR: 18,850 lbs (8,550 kg)

Specifications

POWERTRAIN
Motor: All-electric eAxle with integrated permanent magnet synchronous motor and gearbox
Peak Output: 175hp/129 kW peak
Max Torque: 317ft-lb/430NM
Speed: 64 mph

BATTERY
Size/Modules: M-Size, 2 lithium iron phosphate, liquid-cooled batteries
Range: 70-105 miles
Gradability: 20% with max. torque
Charge Power: Level 2 AC Charging, Level 3 DC Charging
Charge Time AC charger: Approx 6 hours
Charge Time DC charger: Approx 1 hours

DIMENSIONS
Height/Width: 91.3"/84.8"
Wheelbase: 134", 152", 175" or 187"

WEIGHT
Chassis Weight: Approx. 7,500 lbs.
GVWR: 18,850 lbs.

BRAKES
Brake Type: Hydraulic with air assistance

SAFETY
Standard Features: Active Side Assist, Active Brake Assist, Lane Departure Warning, Anti-lock Braking System, Electronic Brake Distribution, Electronic Stability Control, Reverse View Camera System, Electronic Park Lock
